PPR、PERT、PEX
The high-efficiency PP-R, HDPE single tube and one-die double-output pipe production line designed by KOFIYA company is specially aimed at the characteristics of PP-R, HDPE materials, and adopts our self-developed JWS series high-efficiency single screw extruder, equipped with Siemens PLC industrial control system, which can realize the automatic control of the entire production line from extruder to auxiliary machine, with high output and stable extrusion.
Product Details
Model | Pipe Spec(mm) | Extruder | Capacity(Max.)(kg/h) | Total power(kw) |
KFY-PPR-63 ( 单 single) | Ø20-Ø63 | 60×40 | 100-120 | 110 |
KFY-PPR-63 ( 双 double) | Ø20-Ø63 | 60×40 | 200-260 | 150 |
KFY-PERT-32 ( 低速 low speed) | Ø16-Ø32 | 60×40 | 100-120 | 110 |
KFY-PERT-32 ( 高速 speed) | Ø16-Ø3 | 60×40 | 180-220 | 140 |
KFY-PERT-32 ( 双 double) | Ø16-Ø32 | 60×40 | 250-300 | 140 |
KFY-PE/PERT-63 ( 双 double) | Ø20-Ø63 | 60×40 | 250-300 | 140 |
