PE、PC
Suitable for the production of 15-100L various stacking barrels, wide mouth barrels and other chemical packaging barrelsHigh-output extrusion system, storage dieOptional liquid level line extrusion systemOptional hydraulic servo control system
Product Details
| Model | Unit | BM30 | BM50 | BM100 |
| Max product volume | L | 30 | 50 | 100 |
| Dry cycle | Pc/h | 600 | 450 | 360 |
| Die head structure | Accumulating Type | |||
| Main screw diameter | mm | 80 | 90 | 100 |
| Max plasticizing capacity (PE) | kg/h | 120 | 180 | 190 |
| Driving motor | Kw | 37 | 45 | 55 |
| Accumulating volume | L | 5.2 | 6.2 | 12.8 |
| Oil pump motor power | Kw | 15 | 18.5 | 22 |
| Clamping force | Kn | 280 | 400 | 600 |
| Space between platen | mm | 400-900 | 450-1200 | 500-1300 |
| Max mould size | mm | 550*650 | 700*850 | 800*1200 |
| Heating power of die head | Kw | 20 | 28 | 30 |
| Platen size W*H | mm | 740*740 | 880*880 | 1020*1000 |
| Machine dimension L*W*H | m | 4.3*2.2*3.5 | 5.6*2.4*3.8 | 5.5*2.5*4.0 |
| Machine weight | T | 12 | 13.5 | 16 |
| Total power | Kw | 95 | 110 | 135 |
| Note: Informations listed above are for reference only, the production line can be designed by customer’s requirements. | ||||
